In-Line Pro
Advanced Printing with Seamless Integration
The In-line Pro is engineered to bring high-speed, high-quality printing to any production environment with ease. Its sleek, compact printhead allows for installation in tight spaces, while the large 10.2” touchscreen provides intuitive control, making it easy to operate even in fast-paced settings. Fully compliant with Industry 4.0 standards, this printer integrates seamlessly into your production line and IT systems, delivering a powerful solution for industries that prioritize efficiency and user-friendly design.
Get a custom quote for this product using the “add to quote” button below. You can add multiple products to one quote.
HIGHLIGHTED FEATURES
High-Resolution TIJ Printing: Print with 600 dpi resolution for clear, precise text and images.
Flexible Print Options: Full-surface printing up to 100 mm, ideal for larger or unusual product shapes.
Top Speed: Prints up to 240 meters per minute, making it ideal for high-demand settings.
Seamless Integration: Equipped with Ethernet and industry-standard interfaces for quick, reliable setup.
User-Friendly Design: Featuring on-screen wizards, the 10.2” touchscreen simplifies setup and adjustments, prioritizing operator ease and efficiency.
The In-line Pro’s reliability and versatility make it the go-to choice for industries looking to enhance productivity without sacrificing quality.
| Print Technology | Thermal inkjet Printer 2.5 Technology |
| Dimensions | 166 x 250 x 55 mm (control unit), 237 x 53 x 67 mm (1″- print head) |
| Print Height | 1.0 mm – 51 mm (2 in) |
| Number of Print Lines | 1, 2, 3, 4 or more lines of high resolution codes |
| Print Resolution | Vertical 300 dpi Horizontal 300 dpi |
| Maximum Print Speed | 240 m (787 feet) per minute maximum print speed |
| Time & Date | Real-time internal clock |
| Product Sensor | Built-in optical photo-eye and optional external photo-eye |
| Portal Interface | -Intuitive user interface with genuine print preview |
| Display | Capacitive 10.2 in color LCD touchscreen with LED technology |
| Ink Management | Built-in measuring system for ink consumption |
| Power Supply | AC 100-240 V, 50/60 Hz, 1,6 A, automatic changeover |
| Weight | 1,3 kg (control unit), 0,4 kg (1″-rint head) – without ink cartridge |
| Operating Environment | 5-40 °C (41-104 °F) |
| Quality | Made in Germany |
| Printing Elements | Alphanumeric characters and logos, date/time, counter, batch/box number, 1D and 2D barcodes |
| Printing Features | Supports bitmap (BMP) image format |
| Memory Capacity | Internal memory for over 100,000 texts and logos |
| Ink Usage | Automatically calculated for each message and displayed on the touchscreen |
| Connectivity | RJ 45 Ethernet connection incl. DHCP Communication interfaces via MQTT, OPC UA, HTTP request, and TCP-Server Web server for access from every workstation SMTP for automatic reorder of new cartridges by the printer on request |
| Languages | Danish, Dutch, English, French, German, Italian, Korean, Portuguese, Romanian, Serbian, Spanish, Thai,Turkish, Simplified: Arabic, Chinese, Polish, Russian |
| Ink Types | Water-based and solvent-based options |
| Colors | Black, red, blue, yellow, white & green |
| Volume | 42ml ink cartridges |
| Printable Materials | Porous, semi-porous, and non-porous surfaces. |
Swipe left to see more.
