MOTIX 2000 & 4000

At Tourmaline Enterprises, we want to give you the ability to handle all your packaging printing needs with ease and efficiency, and there’s no better way to do that than with our Motix 2000 printer. We’re committed to innovation, and that’s why you can’t find a cutting-edge coding and marking high-speed thermal printer better than our Motix 2000.

If that sounds attractive to you, contact us so that we can work together and make it happen. We’ll help you find a printer that’s easy to integrate and operates at high speeds so that you’ll never need to worry about your printing needs again!

Get a custom quote for this product using the “add to quote” button below. You can add multiple products to one quote.

Add to Quote

Features

High-Resolution Printing Technology
Up to 1200 dpi
High Speed Printing
Printing speeds up to 200 m/min
Large Touchscreen Display

7 in touchscreen display for easy editing (MoTix 2000)
10.01 in touchscreen display for easy editing (MoTix 4000)

Print Height Capabilities

Two 1/2 in printheads can be configured separately or together for a max print height of 2 in

Independent Printhead
Printheads are separated from the controller, multiple configurations possible



Print Technology HP Thermal Inkjet 2.5 Technology
Dimensions 224 x 151 x 38 mm (MoTix 2000) | 281 x 184 x 38 mm (MoTix 4000)
Print Height 1.0 – 25.5 mm (MoTix 2000) | 1-50.8 mm (MoTix 4000)
Multi-Line Printing Group multiple messages together for multi-line printing
Number of Print Lines 1, 2, 3, 4 or more lines of high resolution codes
Print Resolution Vertical 600 dpi Horizontal 40-1200 dpi (Single head)
Maximum Print Speed Up to 200 m/min
Time & Date Real-time internal clock
Product Sensor Built-in optical photoeye
Portal Interface Ethernet, USB 2.0, and 8 pin + 12 pin aviation connector
Display 7 in (MoTix 2000) |  10 in (MoTix 4000)
Ink Management Built-in measuring system for ink consumption
Low Ink Indicator Alert on touchscreen display; alarm light beacon is optional
Working Environment ‘-10°, +55°C
Storage Environment ‘-20°, +70°C
Agency Certifications CE, FCC



Time & Date Custom time and date formatting including expiration date and Julian date
Logos BMP, JPG, PNG
Item numberirng Incremental counter for item sequencing or productino count
Shift Codes Customizable shift codes times and naming with automatic rollover
Barcodes All standard barcode types including 2D barcodes
Pritning Features R-L, L-R, Invert, Rotate, Repeat
Message Length Up to 9.8 ft (3m)
Message Storage Store up to 500 messages
Ink Usage Automatically calculated for each message and displayed on touchscreen
Database Capability Ethernet communication protocol for external communication
Languages English, Korean, and French





Ink Types Water based and solvent based options
Colors Black, Red, Blue, Yellow, White; other colors available upon request
Volume 42ml ink cartridges or 370ml bulk ink solutions
Printable Materials Porous, semi-porous, and non-porous surfaces
