Sojet Elfin 2 & 2C

High-resolution TIJ printer for large character printing

The Elfin-2 is a fully featured system that will print just about anything. You can run the Elfin-2 with one or two print heads, and you can use both the print heads on one side of your case or you can print on opposite sides of your case at the same time. Can also be configured with an uneven surface print head.

Features

Large Touchscreen

7” color touchscreen display

Up to 1 in of print height

Supports up to 2 half-inch print heads

Flexible and Adaptable Design

Independent controller separated from print heads

Backup Capabilities

Backup setting, logos and up to 500 messages



Print Technology HP Thermal Inkjet 2.5 Technology
Controller Dimensions 8.3 in x 5.3 in x 1.46 in H x W x D (210 mm x 135 mm x 37 mm)
Printhead Dimensions 4.9 in x 3.9 in x 1.2 in H x W x D (125 mm x 100 mm x 31 mm)
Print Height Minimum 3/64 in (1mm) Maximum 1 in (25.4 mm)
Number of Print Lines 1, 2, 3, 4 or more lines of high resolution codes
Print Resolution Vertical 300 dpi Horizontal 300 dpi; superb image and text quality
Maximum Print Speed 198 ft/min (60 m/min) @ 300 dpi (default)
Printhead Cable 4 ft length (1.2 m); other lengths available
Time & Date Real-time internal clock
Product Sensor Built-in optical photoeye for each print head
Port Interface Ethernet, USB 2.0, and RS232
Display 7 in (177 mm) full color touchscreen display
Ink Management Built- in measuring system for ink consumption
Low Ink Indicator Alert on touchscreen display; alarm light beacon is optional
Mounting Bracket set for side printing or down printing; spring mechanism is optional
Electrical Requirements 100-240 VAC, 50/60 Hz, 90W (specified AC adapter)
Working Environment WE -10° — +45°C; 10%-85% RH
Storage Environment SE -25° — +55°C; 10%-90% RH
Agency Certifications CE, FCC





Printing Elements Alphanumeric Text, Time & Date, Logos, Item Numbering, Shift Codes, Barcodes, and more
Printing Features Reverse, Invert, Rotate, Repeat
Message Length Up to 9.8 ft (3m)
Message Storage Store up to 500 messages
Ink Usage Automatically calculated for each message and displayed on touchscreen
Database Capability Ethernet communication protocol for external communication
Languages English, Spanish, Portuguese, German, French, Chinese, Japanese, and Russian





Ink Types Water based and solvent based options
Colors Black, Red, Blue, Yellow, White; other colors available upon request
Volume 42ml ink cartridges or 370ml bulk ink solutions
Printable Materials Porous, semi-porous, and non-porous surfaces



Swipe left to see more.
